4Banger Bar: 6 Pod / 24.5"

(0) No Reviews yet
Questions?

Brand: Morimoto

B-2RBAR-24.5IN-MM

$1,370.00

PRODUCT OPTIONS

PART #: 2 x BAF003.2, 1 x BAF005.2, 1 x BAF088SF, 5 x BAF088, 1 x BAF088SB, 1 x BAF130H



DESCRIPTION

Introducing the Morimoto Double Row BangerBar! This bespoke light bar lets you take control -- you spec the power, color, length, and radius. The BangerBar is pre-equipped with 4Banger Pods, adjustable aluminum links, universal end-mounts, and all necessary hardware for a hassle-free assembly. Performance is our priority. The Double Row BangerBars are designed for serious illumination, combining combo, spot, and wide beam pods powered by cutting-edge LEDs from Nichia and Osram. Whether you choose white, yellow, or a white/yellow combo, there's a BangerBar to suit your needs. With adjustable configurations, you can set it straight or curved, adapting to any application. Reliability is paramount. We've invested heavily in ensuring product durability, from efficient heat management with copper DTP PCBs to IP69K-rated weather resistance. Our CNC-machined hardware is built to last, offering peace of mind on every adventure. Power up with confidence -- the Morimoto BangerBar sets a new standard in its segment, backed by a meticulously crafted wire harness with sealed relays, over-molded fuse holders, and more.

FEATURES & BENEFITS

  • Customizable: Available in your choice of lengths, 4Banger light bars can be configured as straight or curved. Customization has never been easier.
  • Light Source: Banger pods are built around the high performance Nichia NCS or Osram HX Boost LEDs for incredible output.
  • All-Weather Versatility: Designed to IP69K weather resistance standards and available in white or yellow output for optimal visibility.
  • Beam Patterns: Curated lens options offer a bright and useful output at both low and high speeds.
  • US-Based Engineering: Designed, engineered, and tested by our team of enthusiasts in Atlanta, GA.

WHAT’S INCLUDED

  • LED Pods: 4x Morimoto 4Banger Combo (White or Yellow)

  • LED Pods: 2x Morimoto 4Banger Wide (White or Yellow)

  • Pod Links: 5x 4Banger Adjustable CNC Links w/ Hardware

  • Center Support Legs: 2x Adjustable Central Support Legs w/ Hardware

  • Universal Mounting Feet: 1x Adjustable Surface Mounts w/ Hardware

  • Relay Harness: 1x Morimoto Switched Power Harness

WARRANTY INFORMATION

This Morimoto product includes a Lifetime limited warranty, serviced and supported by the Morimoto team in Atlanta, GA. This warranty does not cover modifications, alterations, or misuse. For additional information, Click Here. In the event of any issues upon installation, please document it via photo/video and contact us prior to removing the light(s).

TECHNICAL SPECIFICATIONS

  • Peak Luminosity (raw): 8,100lm (NCS), 18,000lm (HXB)

  • Intensity (HXB White): 356,800 Cd (3,568 lux @ 10m)

  • Intensity (HXB Dual Color): 341,400 Cd (3,414 lux @ 10m)

  • Intensity (HXB Yellow): 247,800 Cd (2,478 lux @ 10m)

  • Intensity (NCS White): 250,800 Cd (2,508 lux @ 10m)

  • Intensity (NCS Dual Color): 239,360 Cd (2,394 lux @ 10m)

  • Intensity (NCS Yellow): 172,760 Cd (1,728 lux @ 10m)

  • Power (stabilized): 93.6w (NCS), 252.0w (HXB)

  • Current (amps @ 13.5V DC): 9.00A (NCS), 19.20A (HXB)

COMPATIBILITY

  • Universal: Mounts anywhere w/ included mounting Feet

  • Ideal for: Steel Roof Racks and Bumpers

  • Width: 62.28cm / 24.52in

  • Height: 49.8mm / 1.96in

  • Depth: 59.2mm / 2.33in

  • Weight: 5.38kg / 11.85lb

  • Mounting Width Range: 22.27-27.02" / 56.57-68.63cm

INSTALLATION DOCUMENTS
